              Capsule Technologies

Open Platform Surveillance Hyper-Converged Infrastructure for Video Surveillance Recording, Access Control, Asset Tracking, Video Analytics, License Plate Recognition.

BOSCH BVMS Solution
                South Africa
Exacqvision solution
Axxon Next solutions
              South Africa
Milestone Certified
                Solution south Africa


Capsule Technologies surveillance infrastructure









Up to 100 x HD Channels

180 Mbps of Recording bandwidth

Up to 40 TB raw Storage






CAPSSULE DR460R

CAPS-DR460
2 x Virtual Surveillance Servers
1U - 4-bay


  • Hyper-converged Surveillance Appliance up to 100 HD channels
  • Intel Core Xeon E3 1245v5 Skylake with QuickSync
  • Accelerated by CAPS-OS firmware
  • 16 GBytes of RAM
  • RAID Protection in RAID-5 / RAID-6
  • 2 x 1GE Ethernet Ports
  • Up to 40TBytes of raw storage
  • 4 HDD Slots supporting up to 10TBytes drives
  • 1 x VGA, 1 x DVI, 1 x HDMI – Support of 2 x Monitor
  • Intel Quick Sync supported
  • Certified for BOSCH BVMS, Exacqvision, Milestone, Axxon
DR460R


Up to 200 x HD Channels

360 Mbps of Recording bandwidth

Up to 80 TB raw Storage




Capsule ICE-8
                  8bay NVR

CAPS-ICE-8
2 x Virtual Surveillance Servers
2U - 8-bay



  • Hyper-converged Surveillance Appliance up to 200 HD channels
  • Intel Core Xeon E3 1230v5
  • Accelerated by CAPS-OS firmware
  • 16 GBytes of RAM
  • RAID Protection in RAID-5 / RAID-6
  • 2 x 1GE Ethernet Ports
  • Up to 80TBytes of raw storage
  • 8 HDD Slots supporting up to 10TBytes drives
  • 1 x VGA
  • Certified for BOSCH BVMS, Exacqvision, Milestone, Axxon
ICE8 Datasheet


Up to 400 x HD Channels

740 Mbps of Recording bandwidth

Up to 160 TB raw Storage



Capsule
                  ICE-16 16-bay

CAPS-ICE-16
  3 x Virtual Surveillance Servers
3U / 16-bay

  • Hyper-converged Surveillance Appliance up to 400 channels
  • Intel Core Xeon E3 1240v5
  • Accelerated by CAPS-OS firmware
  • 32 GBytes of RAM
  • RAID Protection in RAID-5 / RAID-6
  • 4 x 1GE Ethernet Ports
  • Up to 160 TBytes of raw storage
  • 16 HDD Slots supporting up to 10TBytes drives
  • 1 x VGA
  • Certified for BOSCH BVMS, Exacqvision, Milestone, Axxon
ICE16 Datasheet


Up to 600 x HD Channels

  1100 Mbps of Recording bandwidth

Up to 240 TB raw Storage


Capsule
                  ICE-24 24bay

CAPS-ICE-24
  6 x Virtual Surveillance Servers
4U / 24-bay


  • Hyper-converged Surveillance Appliance up to 600 channels
  • Dual active-active controllers for scalability and redundancy
  • Intel Core Xeon E3 1240v5
  • Accelerated by CAPS-OS firmware
  • 64 GBytes of RAM
  • RAID Protection in RAID-5 / RAID-6
  • 8 x 1GE Ethernet Ports
  • Up to 240TBytes of raw storage
  • 24 HDD Slots supporting up to 10TBytes drives
  • 1 x VGA
  • Certified for BOSCH BVMS, Exacqvision, Milestone, Axxon
ICE24 Datasheet


Up to 600 x HD Channels

1100 Mbps of Recording bandwidth

Up to 480 TB raw Storage



Capsule
                  DR4860 48-bay

CAPS-DR4860
 8 x Virtual Surveillance Servers
4U / 48-bay


  • Hyper-converged Surveillance Appliance up to 600 channels
  • Dual Intel Xeon E5 2620v4
  • Accelerated by CAPS-OS firmware
  • 64 GBytes of RAM
  • RAID Protection in RAID-5 / RAID-6
  • 8 x 1GE Ethernet Ports
  • Up to 480TBytes of raw storage
  • 48 HDD Slots supporting up to 10TBytes drives
  • 1 x VGA
  • Certified for BOSCH BVMS, Exacqvision, Milestone, Axxon
DR4860 Datasheet


Up to 600 x HD Channels

1100 Mbps of Recording bandwidth

Up to 900TB raw Storage


Capsule
                  DR9060 90-bay

CAPS-DR9060
 8 x Virtual Surveillance Servers
4U / 90-bay


  • Hyper-converged Surveillance Appliance up to 600 channels
  • Dual Intel Xeon E5 2620v4
  • Accelerated by CAPS-OS firmware
  • 64 GBytes of RAM
  • RAID Protection in RAID-5 / RAID-6
  • 4 x 10GE Ethernet Ports
  • Up to 900TBytes of raw storage
  • 90 HDD Slots supporting up to 10TBytes drives
  • 1 x VGA
  • Certified for BOSCH BVMS, Exacqvision, Milestone, Axxon
DR9060 Datasheet












Capstarget is a small footprint Virtual Machine developed by Capsule Technologies acting as iSCSI target




Device
Drives
Channels
Performance
Capsule ICE-8
8
200
360 Mbit/s
Capsule ICE-16
16
408
740 Mbit/s
Capsule ICE-24
24
640
1160 Mbit/s

BOSCH BVMS Test Plan Report for CAPS-ICE8
BOSCH BVMS Test Plan Report for CAPS-ICE16 BOSCH BVMS Test Plan Report for CAPS-ICE24











The Milestone Technology Partner (MTP) Certification program seeks to confirm that server, storage and network solutions provided by qualified MTP vendors meet the performance benchmarks required to support the Milestone XProtect VMS applications,
and to measure the maximum performance available to Milestone customers if they choose to build a solution using certified MTP products.

Three versions of the Capsule Appliances were tested, and all three far exceeded the performance benchmarks required for certification.
Performance tests focused on finding the maximum number of cameras each Capsule Appliance could support.




CAPS System
Cameras
Stream Size (Mbps)
Disk I/O (MBytes/s)
Read Latency
CPU%
Lost Frames
CAPS-ICE-16, 16-bay
90
9.06
94.83
0.67 ms
46.59
0%
CAPS-ICE-24, 24-bay
200
6.65
165.57
1.67 ms
75.06
0.52%
CAPS-DR4860, 48-bay
300
6.45
233.67
0.96 ms
78.6
0.021%

Capsule - Milestone White Paper
ICE-16 Certification Certificate
ICE-24 Certification Certificate
DR4860 Certification Certificate












Capsule ICE Technology offers a perfectly designed Software Defined Infrastructure for all the Tyco products.

Capsule supports pre-configured virtual appliances for Exacqvision, CEM and Kantech, enabling Tyco Security products into a flexible and scalable environment.

The typical building block design offers performance and reliability beyond any legacy server / storage architecture.
